Overview
The SX-80 is an 80 kW class plasma spray system built for ceramic and metal powder coatings on industrial parts. It is the platform behind most of our roll, cylinder and shaft coating work: chromium oxide, alumina, zirconia and carbide powders, sprayed at controlled standoff with closed-loop gas and powder control.
Control and quality
- Controller: Siemens PLC with bilingual (English / Chinese) HMI
- Temperature control: accuracy of +/-1 C, which keeps the substrate in the window where the coating bonds properly
- Uniformity: measured about 30% better than our previous generation of manual-parameter systems, mainly from stable gas flow and repeatable traverse
- Energy: around 20% lower consumption than comparable thyristor-controlled supplies thanks to the inverter power supply
- Diagnostics: built-in fault self-diagnosis with plain-language alarms on the HMI
What is included
Power supply, control cabinet, plasma gun, powder feeder, water chiller, gas panel and the parameter package for the customer's first coating job. Commissioning, operator training and the spare parts list are part of the delivery.
Where it fits
The SX-80 suits coating shops and manufacturers who need one system that covers both ceramics and carbides at production output - rolls, cylinders, sleeves, wear plates and graphite furniture. For higher power or fully automated lines the SX-90 and the turnkey booth configurations are the next step up.
Frequently asked questions
What is the SX-80 plasma spray system used for?
Ceramic and metal powder coatings - chromium oxide, alumina, zirconia and carbide powders - on industrial rolls, cylinder surfaces, shafts and wear parts.
What is the power and control configuration?
An 80 kW class inverter plasma power supply with a Siemens PLC and bilingual HMI, closed-loop control of gas flow, current and powder feed, with recipes stored per coating.
What is included with the system?
Power supply, control cabinet, plasma gun, powder feeder, water chiller, gas panel and the parameter package for the customer's first coating, plus commissioning and operator training.
