Newly upgraded SX-90 plasma spraying equipment

Newly upgraded SX-90 plasma spraying equipment

Overview

This is a complete plasma spray production line built around the SX-90 system: spray booth, dust collector, manipulator, chiller and control system supplied as one package, installed and commissioned in the customer's workshop.

Why the SX-90 control cabinet

The SX-90 cabinet uses Alicat mass flow controllers imported from the United States to regulate plasma gas. Unstable gas pressure and flow are the usual cause of flame fluctuation and voltage swing in plasma spraying; holding flow stable removes that variation, which stabilises output power and makes every parameter closed-loop rather than operator-dependent.

  • Terminal: touch-screen interface replacing the older button panel
  • Recipes: spray parameters stored per powder and per part, recalled by name
  • Alarms: fault messages shown on screen with the relevant subsystem
  • Access levels: administrator can edit and save parameters, operator can only run them
  • Serviceability: reserved interfaces for remote support and later expansion

Line composition

Plasma power supply and control cabinet, SG-100 plasma gun, a combined water / gas / electricity safety centre, soundproof spray booth with extraction, pulse dust collector, manipulator or turntable, water chiller and the PLC control system. Core components are imported brands, which is why the after-sales risk on this line is low.

Training and handover

Commissioning includes parameter development on the customer's own parts, operator training on start-up, shutdown and routine maintenance, and a documented parameter set so the line can be restarted by a new shift without guesswork.

Frequently asked questions

What does the SX-90 based line include?

Plasma power supply and control cabinet, SG-100 gun, water/gas/electricity safety centre, spray booth with extraction, dust collector, manipulator or turntable, chiller and the PLC control system.

Why use imported mass flow controllers?

Alicat mass flow controllers hold gas flow stable, which removes the flame fluctuation and voltage swing that unstable gas supply causes. Stable gas flow means stable power output and repeatable coating quality.

Can operators without experience run the system?

Yes. Parameters are stored as recipes per powder and part, the HMI shows alarms in plain language, and access is split between administrator (can edit recipes) and operator (can only run them). Training is included.
